AutoPhi V20 Branch Series -- 100 chip datasheets, foundry handoff, GDSII layouts, architecture docs (Epiphany platform)
First to market

Publicly online since 2010 · U.S. patent applications since 2012 · inventions offered since 2014. The work of Christopher Gabriel Brown, independently documented.

First posted: · Last updated:
Downloads
Instant download

Downloads immediately on checkout — the CD GDSII Generator (AES-256 encrypted). Open with 7-Zip, WinRAR, or macOS Archive Utility using password CRIONE99KEY. Founder Access Pass credit (code FAP99CREDIT) applies at checkout.

AutoPhi V20 Branch Series -- Epiphany Architecture Schematic Package

Complete schematical program package for the AutoPhi V20 Branch Series (chips 301-400), featuring the revolutionary Epiphany architecture. The V20 platform introduces 10mm PCIe board integration, AES substrate technology, and enhanced GDSII layout files for direct foundry submission. Each of the 100 chips in this series includes full datasheets, foundry handoff documents, and specifications optimized for the Branch performance tier.

  • Process Node: 1.5 nm -- V20 Epiphany quantum-classical hybrid
  • Performance: up to 4.43 ZFLOPS
  • Power: as low as 680.4 W (self-sufficient, sub-100W)
  • Qubits: up to 2,043,642 physical qubits with QEC
  • Die Size: 36x36 -- optimized for PCIe 5.0 integration
  • Includes GDSII layout files for foundry submission
  • Architecture docs: board integration, AES substrate, PCIe mounting

Package Contents

  • 100 IC chip datasheets (.md) -- complete technical specifications
  • 100 foundry handoff documents (.md) -- fabrication-ready parameters
  • 100 chip specifications (.json) -- machine-readable specs
  • GDSII layout files (.gds) -- V20 Epiphany seed and epiphany layouts
  • Architecture documentation -- overview, PCIe mounting, board integration, AES substrate
  • Combined Bill of Materials (.csv) -- all 100 chips summarized
  • Product image and README with patent coverage

Patent Coverage

  • 18/370,908 -- Quantum Battery System
  • 19/403,339 -- Optical Quantum Battery
  • 3561/2876 -- Light Trigger Semiconductor
  • 1026 -- Battery + Generator + Recycle
  • 1096-1098 -- EM Field Control
  • 1105 -- Wind Recycle Generator
  • 3559 -- Staircase Mirror Chip
