AutoPhi V19 Schematic #30 -- MIL-38999 Aerospace
Complete KiCad 10 schematic package for the AutoPhi V19 Quantum PCIe 5.0 accelerator card with MIL-38999 Aerospace I/O bracket. This design features an AutoPhi BGA-based quantum processing platform, five DS80PCI810 PCIe 5.0 retimers, four DDR3 SDRAM banks, and a comprehensive power delivery network. The schematic is fully annotated with net labels, hierarchical sheets, and design rule constraints suitable for professional PCB layout.
- PCIe 5.0 x16 interface -- 128 GB/s bidirectional bandwidth
- 18-layer PCB stackup -- F.Cu + In1..In16 + B.Cu
- AutoPhi BGA socket envelope supports up to 95 mm interchange planning
- 5x DS80PCI810 retimers -- signal conditioning for all 16 lanes
- 4x DDR3 SDRAM (FBGA-96) -- high-speed local memory
- 352 components total with 323 signal nets
- 323 signal nets with impedance-controlled routing constraints
- MIL-38999 Aerospace I/O bracket for external connectivity
- Conservative external board input policy: 75W max
Package Contents
- KiCad 10 schematic file (.kicad_sch)
- Bill of Materials spreadsheet (.csv)
- KiCad netlist for PCB layout (.net)
- Product image / board render (.webp)
- README with patent and specification details
