AutoPhi V18-Seed Voxel Processor -- Pro Series #272727
AutoPhi V18 Pro 507: 40.59 TFLOPS Tera-class | 10nm | 11541 Qubits | Professional-grade hybrid computing
Overview
The AutoPhi V18 Pro 507 is a tera-class quantum-classical hybrid processor built on the 18-seed voxel DNA architecture at 10nm process technology. It delivers 40.59 TFLOPS peak performance with 6.624 TOPS AI acceleration across a 305x305 voxel grid (93,025 total voxels) stacked 47 layers deep (3 stack units of 18). Quantum subsystem: 11,541 qubits at 97.156% fidelity (error rate <2.844%). Clocked at 3.195 GHz with 6.92 TB/s memory bandwidth over 37 nanophotonic channels. Neuromorphic engine: 16.4K spiking neurons for event-driven AI processing. Power envelope: 112.4 W with 72% reduction vs 130nm baseline. Integrates 6/9 AutoPhi core technologies. Three-chromosome DNA encoding: 66-bit electron strand, 8 quantum instructions (atomic strand), 10 photon opcodes (light strand). Light-trigger initiated.
Key Specifications
| Performance | 40.59 TFLOPS (Tera-class) |
| Process Node | 10nm |
| Clock Speed | 3.195 GHz |
| AI Acceleration | 6.624 TOPS |
| Quantum Subsystem | 11,541 qubits at 97.156% fidelity (error rate <2.844%) |
| Memory Bandwidth | 6.92 TB/s |
| Nanophotonic Channels | 37 |
| Neuromorphic Engine | 16.4K spiking neurons |
| Power Envelope | 112.4 W |
| Power Reduction vs 130nm | 72% |
| Voxel Grid | 305x305 (93025 voxels, 47 layers, 3 stack units of 18) |
| Compute Type | CPU + GPU + light-DPU |
| Form Factor | Server |
| LED Power Recycling | 82.4% |
| EM Cooling Efficiency | 78.8% (zero moving parts) |
| Quantum Battery Layers | 4 |
| DNA Encoding | 66-bit electron strand, 8 quantum instructions, 10 photon opcodes |
| Instruction Set | Red=ADD, Blue=SUB, Green=MUL, Yellow=DIV, Cyan=LOAD, Magenta=STORE, White=BRANCH, UV=QGATE, IR=SYNC, Orange=MEASURE |
Target Markets
- Professional HPC
- AI training clusters
- drug discovery pipelines
Applications
- Drug candidate screening
- CFD simulation
- large language model fine-tuning
- weather prediction
Manufacturing & Fabrication
| Foundry | Samsung 10LPE / TSMC N10 |
| PDK | 10nm PDK (NDA) |
| EDA Flow | Commercial (Synopsys/Cadence) |
| Readiness | Architecture Ready -- Awaiting 10nm PDK |
Manufacturing Steps
- Obtain 10nm PDK under NDA
- Synthesize -> P&R -> DRC/LVS
- Package per FOUNDRY_STANDARDS.md
- Submit via foundry portal
Deliverables
- GDSII (mask layout)
- LEF (library exchange)
- DEF (design exchange)
- Gate-level netlist (Verilog)
- DRC report
- LVS report
- FOUNDRY_HANDOFF_SIMPLE.txt
- RTL (autophi_light_cpu_core.v + autophi_quantum_cpu_core.v + autophi_hybrid_cpu_top.v)
- Synthesis scripts
- P&R configurations
- Manufacturing documentation
- Performance projections
RTL Design Files
autophi_light_cpu_core.vautophi_quantum_cpu_core.vautophi_hybrid_cpu_top.v
Acquisition Path
This product is available through CGB's 4-step acquisition path. The current price is shown in your cart and on the live storefront page.
- Step 1 — Proof of Function: public, $1.69 each.
- Step 2 — Mathematical Deposition: reading material under mutual NDA.
- Step 3 — Evaluation License: hands-on evaluation under NDA; fee credits toward Step 4.
- Step 4 — Full Acquisition:
