AutoPhi V18-Achievement -- Pro Series #478
Publicly online since 2010 · U.S. patent applications since 2012 · inventions offered since 2014. The work of Christopher Gabriel Brown, independently documented.
Downloads immediately on checkout — the CD GDSII Generator (AES-256 encrypted). Open with 7-Zip, WinRAR, or macOS Archive Utility using password CRIONE99KEY. Founder Access Pass credit (code FAP99CREDIT) applies at checkout.
AutoPhi V18-Seed Voxel Processor -- Pro Series #6a6a6a
AutoPhi V18 Pro 478: 13.03 TFLOPS Tera-class | 14nm | 7497 Qubits | Professional-grade hybrid computing
Overview
The AutoPhi V18 Pro 478 is a tera-class quantum-classical hybrid processor built on the 18-seed voxel DNA architecture at 14nm process technology. It delivers 13.03 TFLOPS peak performance with 4.001 TOPS AI acceleration across a 254x254 voxel grid (64,516 total voxels) stacked 41 layers deep (3 stack units of 18). Quantum subsystem: 7,497 qubits at 97.959% fidelity (error rate <2.041%). Clocked at 3.459 GHz with 3.66 TB/s memory bandwidth over 29 nanophotonic channels. Neuromorphic engine: 8.0K spiking neurons for event-driven AI processing. Power envelope: 74.2 W with 65% reduction vs 130nm baseline. Integrates 6/9 AutoPhi core technologies. Three-chromosome DNA encoding: 58-bit electron strand, 7 quantum instructions (atomic strand), 9 photon opcodes (light strand). Light-trigger initiated.
Key Specifications
| Performance | 13.03 TFLOPS (Tera-class) |
| Process Node | 14nm |
| Clock Speed | 3.459 GHz |
| AI Acceleration | 4.001 TOPS |
| Quantum Subsystem | 7,497 qubits at 97.959% fidelity (error rate <2.041%) |
| Memory Bandwidth | 3.66 TB/s |
| Nanophotonic Channels | 29 |
| Neuromorphic Engine | 8.0K spiking neurons |
| Power Envelope | 74.2 W |
| Power Reduction vs 130nm | 65% |
| Voxel Grid | 254x254 (64516 voxels, 41 layers, 3 stack units of 18) |
| Compute Type | CPU + GPU + light-DPU |
| Form Factor | Server |
| LED Power Recycling | 80.5% |
| EM Cooling Efficiency | 77.3% (zero moving parts) |
| Quantum Battery Layers | 3 |
| DNA Encoding | 58-bit electron strand, 7 quantum instructions, 9 photon opcodes |
| Instruction Set | Red=ADD, Blue=SUB, Green=MUL, Yellow=DIV, Cyan=LOAD, Magenta=STORE, White=BRANCH, UV=QGATE, IR=SYNC |
Target Markets
- Professional HPC
- AI training clusters
- drug discovery pipelines
Applications
- Drug candidate screening
- CFD simulation
- large language model fine-tuning
- weather prediction
Manufacturing & Fabrication
| Foundry | Samsung 14LPE / Intel 14nm / TSMC 16FF |
| PDK | 14nm PDK (NDA) |
| EDA Flow | Commercial (Synopsys/Cadence) |
| Readiness | Architecture Ready -- Awaiting 14nm PDK |
Manufacturing Steps
- Obtain 14nm PDK under NDA
- Run synthesis with 14nm stdcells
- P&R -> DRC/LVS with foundry decks
- Package per FOUNDRY_STANDARDS.md
- Submit via foundry design portal
Deliverables
- GDSII (mask layout)
- LEF (library exchange)
- DEF (design exchange)
- Gate-level netlist (Verilog)
- DRC report
- LVS report
- FOUNDRY_HANDOFF_SIMPLE.txt
- RTL (autophi_light_cpu_core.v + autophi_quantum_cpu_core.v + autophi_hybrid_cpu_top.v)
- Synthesis scripts
- P&R configurations
- Manufacturing documentation
- Performance projections
RTL Design Files
autophi_light_cpu_core.vautophi_quantum_cpu_core.vautophi_hybrid_cpu_top.v
Acquisition Path
This product is available through CGB's 4-step acquisition path. The current price is shown in your cart and on the live storefront page.
- Step 1 — Proof of Function: public, $1.69 each.
- Step 2 — Mathematical Deposition: reading material under mutual NDA.
- Step 3 — Evaluation License: hands-on evaluation under NDA; fee credits toward Step 4.
- Step 4 — Full Acquisition:
