AutoPhi V18-Achievement -- Peak Series #689
Publicly online since 2010 · U.S. patent applications since 2012 · inventions offered since 2014. The work of Christopher Gabriel Brown, independently documented.
AutoPhi V18-Seed Voxel Processor -- Peak Series #689
AutoPhi V18 Peak 689: 50.66 PFLOPS Peta-class | 5nm | 156377 Qubits | Maximum single-die performance
Overview
The AutoPhi V18 Peak 689 is a peta-class quantum-classical hybrid processor built on the 18-seed voxel DNA architecture at 5nm process technology. It delivers 50.66 PFLOPS peak performance with 156.861 TOPS AI acceleration across a 876x876 voxel grid (767,376 total voxels) stacked 120 layers deep (7 stack units of 18). Quantum subsystem: 156,377 qubits at 98.844% fidelity (error rate <1.156%) with 40,127 QEC-protected logical qubits. Clocked at 6.321 GHz with 381.34 TB/s memory bandwidth over 188 nanophotonic channels. Neuromorphic engine: 1.5M spiking neurons for event-driven AI processing. Power envelope: 1.9 kW with 83% reduction vs 130nm baseline. Integrates 8/9 AutoPhi core technologies. Three-chromosome DNA encoding: 140-bit electron strand, 18 quantum instructions (atomic strand), 13 photon opcodes (light strand). Light-trigger initiated.
Key Specifications
| Performance | 50.66 PFLOPS (Peta-class) |
| Process Node | 5nm |
| Clock Speed | 6.321 GHz |
| AI Acceleration | 156.861 TOPS |
| Quantum Subsystem | 156,377 qubits at 98.844% fidelity (error rate <1.156%) |
| QEC Logical Qubits | 40,127 |
| Memory Bandwidth | 381.34 TB/s |
| Nanophotonic Channels | 188 |
| Neuromorphic Engine | 1.5M spiking neurons |
| Power Envelope | 1.9 kW |
| Power Reduction vs 130nm | 83% |
| Voxel Grid | 876x876 (767376 voxels, 120 layers, 7 stack units of 18) |
| Compute Type | CPU + full-GPU + DPU |
| Form Factor | HPC node |
| LED Power Recycling | 90% |
| EM Cooling Efficiency | 88.5% (zero moving parts) |
| Quantum Battery Layers | 10 |
| DNA Encoding | 140-bit electron strand, 18 quantum instructions, 13 photon opcodes |
| Instruction Set | Red=ADD, Blue=SUB, Green=MUL, Yellow=DIV, Cyan=LOAD, Magenta=STORE, White=BRANCH, UV=QGATE, IR=SYNC, Orange=MEASURE, Violet=ENTANGLE, Lime=NEURON, Teal=DMA |
Target Markets
- High-performance computing nodes
- large-scale AI inference
- climate modeling
Applications
- Full AI model training
- protein folding
- nuclear simulation
- real-time fraud detection at scale
Pricing & Economics
| AES Tier | AES Tier 3 -- Peak ($2M - $10M) |
| IP Valuation | $3.24B |
| AES COGS | $2.83M |
| AES Sell Price | $9.42M |
| Gross Margin | 70% |
| Revenue Multiple | 30x |
| 5-Year Revenue Projection | $282.62M |
| ROI | 233% |
| Warranty & Support | 5-year premium; 24x7 support; dedicated engineer |
Manufacturing & Fabrication
| Foundry | TSMC N5 / Samsung 5LPE |
| PDK | 5nm PDK (NDA) |
| EDA Flow | Commercial (Synopsys/Cadence) + EUV |
| Readiness | Architecture Ready -- Awaiting 5nm NDA/PDK |
Manufacturing Steps
- Obtain TSMC N5 or Samsung 5LPE PDK under NDA
- Synthesize -> P&R with EUV-aware flow
- DRC/LVS with foundry decks
- Package per FOUNDRY_STANDARDS.md
- Submit via foundry portal
Deliverables
- GDSII (mask layout)
- LEF (library exchange)
- DEF (design exchange)
- Gate-level netlist (Verilog)
- DRC report
- LVS report
- FOUNDRY_HANDOFF_SIMPLE.txt
- RTL (autophi_light_cpu_core.v + autophi_quantum_cpu_core.v + autophi_hybrid_cpu_top.v)
- Synthesis scripts
- P&R configurations
- Manufacturing documentation
- Performance projections
RTL Design Files
autophi_light_cpu_core.vautophi_quantum_cpu_core.vautophi_hybrid_cpu_top.v
