AutoPhi V18-Achievement -- Peak Series #618
Publicly online since 2010 · U.S. patent applications since 2012 · inventions offered since 2014. The work of Christopher Gabriel Brown, independently documented.
AutoPhi V18-Seed Voxel Processor -- Peak Series #618
AutoPhi V18 Peak 618: 3.14 PFLOPS Peta-class | 7nm | 57641 Qubits | Maximum single-die performance
Overview
The AutoPhi V18 Peak 618 is a peta-class quantum-classical hybrid processor built on the 18-seed voxel DNA architecture at 7nm process technology. It delivers 3.14 PFLOPS peak performance with 45.64 TOPS AI acceleration across a 591x591 voxel grid (349,281 total voxels) stacked 84 layers deep (5 stack units of 18). Quantum subsystem: 57,641 qubits at 98.617% fidelity (error rate <1.383%) with 13,562 QEC-protected logical qubits. Clocked at 5.646 GHz with 79.83 TB/s memory bandwidth over 100 nanophotonic channels. Neuromorphic engine: 254.3K spiking neurons for event-driven AI processing. Power envelope: 642.1 W with 78% reduction vs 130nm baseline. Integrates 7/9 AutoPhi core technologies. Three-chromosome DNA encoding: 104-bit electron strand, 13 quantum instructions (atomic strand), 11 photon opcodes (light strand). Light-trigger initiated.
Key Specifications
| Performance | 3.14 PFLOPS (Peta-class) |
| Process Node | 7nm |
| Clock Speed | 5.646 GHz |
| AI Acceleration | 45.64 TOPS |
| Quantum Subsystem | 57,641 qubits at 98.617% fidelity (error rate <1.383%) |
| QEC Logical Qubits | 13,562 |
| Memory Bandwidth | 79.83 TB/s |
| Nanophotonic Channels | 100 |
| Neuromorphic Engine | 254.3K spiking neurons |
| Power Envelope | 642.1 W |
| Power Reduction vs 130nm | 78% |
| Voxel Grid | 591x591 (349281 voxels, 84 layers, 5 stack units of 18) |
| Compute Type | CPU + full-GPU + DPU |
| Form Factor | HPC node |
| LED Power Recycling | 89.8% |
| EM Cooling Efficiency | 84.7% (zero moving parts) |
| Quantum Battery Layers | 8 |
| DNA Encoding | 104-bit electron strand, 13 quantum instructions, 11 photon opcodes |
| Instruction Set | Red=ADD, Blue=SUB, Green=MUL, Yellow=DIV, Cyan=LOAD, Magenta=STORE, White=BRANCH, UV=QGATE, IR=SYNC, Orange=MEASURE, Violet=ENTANGLE |
Target Markets
- High-performance computing nodes
- large-scale AI inference
- climate modeling
Applications
- Full AI model training
- protein folding
- nuclear simulation
- real-time fraud detection at scale
Pricing & Economics
| AES Tier | AES Tier 3 -- Peak ($2M - $10M) |
| IP Valuation | $690.63M |
| License Price (this store) | $2.07M |
| AES COGS | $2.48M |
| AES Sell Price | $8.27M |
| Gross Margin | 70% |
| Revenue Multiple | 30x |
| 5-Year Revenue Projection | $248.11M |
| ROI | 233% |
| Warranty & Support | 5-year premium; 24x7 support; dedicated engineer |
Manufacturing & Fabrication
| Foundry | TSMC N7 / Samsung 7LPP |
| PDK | 7nm PDK (NDA) |
| EDA Flow | Commercial (Synopsys/Cadence) |
| Readiness | Architecture Ready -- Awaiting 7nm NDA/PDK |
Manufacturing Steps
- Obtain TSMC N7 or Samsung 7LPP PDK under NDA
- Run synthesis with 7nm stdcells
- P&R -> TSMC/Samsung DRC/LVS decks
- Package GDSII, LEF, DEF, netlist per FOUNDRY_STANDARDS.md
- Submit via TSMC design portal or Samsung foundry portal
Deliverables
- GDSII (mask layout)
- LEF (library exchange)
- DEF (design exchange)
- Gate-level netlist (Verilog)
- DRC report
- LVS report
- FOUNDRY_HANDOFF_SIMPLE.txt
- RTL (autophi_light_cpu_core.v + autophi_quantum_cpu_core.v + autophi_hybrid_cpu_top.v)
- Synthesis scripts
- P&R configurations
- Manufacturing documentation
- Performance projections
RTL Design Files
autophi_light_cpu_core.vautophi_quantum_cpu_core.vautophi_hybrid_cpu_top.v
