AutoPhi V18-Achievement -- Peak Series #574
Publicly online since 2010 · U.S. patent applications since 2012 · inventions offered since 2014. The work of Christopher Gabriel Brown, independently documented.
Downloads immediately on checkout — the CD GDSII Generator (AES-256 encrypted). Open with 7-Zip, WinRAR, or macOS Archive Utility using password CRIONE99KEY. Founder Access Pass credit (code FAP99CREDIT) applies at checkout.
AutoPhi V18-Seed Voxel Processor -- Peak Series #676767
AutoPhi V18 Peak 574: 560.08 TFLOPS Tera-class | 10nm | 30700 Qubits | Maximum single-die performance
Overview
The AutoPhi V18 Peak 574 is a tera-class quantum-classical hybrid processor built on the 18-seed voxel DNA architecture at 10nm process technology. It delivers 560.08 TFLOPS peak performance with 21.236 TOPS AI acceleration across a 458x458 voxel grid (209,764 total voxels) stacked 67 layers deep (4 stack units of 18). Quantum subsystem: 30,700 qubits at 98.766% fidelity (error rate <1.234%) with 6,817 QEC-protected logical qubits. Clocked at 5.207 GHz with 30.29 TB/s memory bandwidth over 68 nanophotonic channels. Neuromorphic engine: 85.7K spiking neurons for event-driven AI processing. Power envelope: 331.3 W with 72% reduction vs 130nm baseline. Integrates 7/9 AutoPhi core technologies. Three-chromosome DNA encoding: 87-bit electron strand, 11 quantum instructions (atomic strand), 11 photon opcodes (light strand). Light-trigger initiated.
Key Specifications
| Performance | 560.08 TFLOPS (Tera-class) |
| Process Node | 10nm |
| Clock Speed | 5.207 GHz |
| AI Acceleration | 21.236 TOPS |
| Quantum Subsystem | 30,700 qubits at 98.766% fidelity (error rate <1.234%) |
| QEC Logical Qubits | 6,817 |
| Memory Bandwidth | 30.29 TB/s |
| Nanophotonic Channels | 68 |
| Neuromorphic Engine | 85.7K spiking neurons |
| Power Envelope | 331.3 W |
| Power Reduction vs 130nm | 72% |
| Voxel Grid | 458x458 (209764 voxels, 67 layers, 4 stack units of 18) |
| Compute Type | CPU + full-GPU + DPU |
| Form Factor | Server |
| LED Power Recycling | 86.9% |
| EM Cooling Efficiency | 82.4% (zero moving parts) |
| Quantum Battery Layers | 6 |
| DNA Encoding | 87-bit electron strand, 11 quantum instructions, 11 photon opcodes |
| Instruction Set | Red=ADD, Blue=SUB, Green=MUL, Yellow=DIV, Cyan=LOAD, Magenta=STORE, White=BRANCH, UV=QGATE, IR=SYNC, Orange=MEASURE, Violet=ENTANGLE |
Target Markets
- High-performance computing nodes
- large-scale AI inference
- climate modeling
Applications
- Full AI model training
- protein folding
- nuclear simulation
- real-time fraud detection at scale
Manufacturing & Fabrication
| Foundry | Samsung 10LPE / TSMC N10 |
| PDK | 10nm PDK (NDA) |
| EDA Flow | Commercial (Synopsys/Cadence) |
| Readiness | Architecture Ready -- Awaiting 10nm PDK |
Manufacturing Steps
- Obtain 10nm PDK under NDA
- Synthesize -> P&R -> DRC/LVS
- Package per FOUNDRY_STANDARDS.md
- Submit via foundry portal
Deliverables
- GDSII (mask layout)
- LEF (library exchange)
- DEF (design exchange)
- Gate-level netlist (Verilog)
- DRC report
- LVS report
- FOUNDRY_HANDOFF_SIMPLE.txt
- RTL (autophi_light_cpu_core.v + autophi_quantum_cpu_core.v + autophi_hybrid_cpu_top.v)
- Synthesis scripts
- P&R configurations
- Manufacturing documentation
- Performance projections
RTL Design Files
autophi_light_cpu_core.vautophi_quantum_cpu_core.vautophi_hybrid_cpu_top.v
Acquisition Path
This product is available through CGB's 4-step acquisition path. The current price is shown in your cart and on the live storefront page.
- Step 1 — Proof of Function: public, $1.69 each.
- Step 2 — Mathematical Deposition: reading material under mutual NDA.
- Step 3 — Evaluation License: hands-on evaluation under NDA; fee credits toward Step 4.
- Step 4 — Full Acquisition:
