AutoPhi V18-Achievement -- Mini Series #190
Publicly online since 2010 · U.S. patent applications since 2012 · inventions offered since 2014. The work of Christopher Gabriel Brown, independently documented.
Downloads immediately on checkout — the CD GDSII Generator (AES-256 encrypted). Open with 7-Zip, WinRAR, or macOS Archive Utility using password CRIONE99KEY. Founder Access Pass credit (code FAP99CREDIT) applies at checkout.
AutoPhi V18-Seed Voxel Processor -- Mini Series #5f5f5f
AutoPhi V18 Mini 190: 164.21 MFLOPS Mega-class | 65nm | 70 Qubits | Compact quantum-classical computing
Overview
The AutoPhi V18 Mini 190 is a mega-class quantum-classical hybrid processor built on the 18-seed voxel DNA architecture at 65nm process technology. It delivers 164.21 MFLOPS peak performance with 0.027 TOPS AI acceleration across a 28x28 voxel grid (784 total voxels) stacked 7 layers deep (1 stack units of 18). Quantum subsystem: 70 qubits at 95.541% fidelity (error rate <4.459%). Clocked at 0.445 GHz with 6.4 GB/s memory bandwidth over 2 nanophotonic channels. Power envelope: 896.8 mW with 30% reduction vs 130nm baseline. Integrates 3/9 AutoPhi core technologies. Three-chromosome DNA encoding: 18-bit electron strand, 2 quantum instructions (atomic strand), 4 photon opcodes (light strand). Light-trigger initiated.
Key Specifications
| Performance | 164.21 MFLOPS (Mega-class) |
| Process Node | 65nm |
| Clock Speed | 0.445 GHz |
| AI Acceleration | 0.027 TOPS |
| Quantum Subsystem | 70 qubits at 95.541% fidelity (error rate <4.459%) |
| Memory Bandwidth | 6.4 GB/s |
| Nanophotonic Channels | 2 |
| Power Envelope | 896.8 mW |
| Power Reduction vs 130nm | 30% |
| Voxel Grid | 28x28 (784 voxels, 7 layers, 1 stack units of 18) |
| Compute Type | CPU + light-GPU |
| Form Factor | Client / embedded |
| LED Power Recycling | 61.3% |
| EM Cooling Efficiency | 62.1% (zero moving parts) |
| DNA Encoding | 18-bit electron strand, 2 quantum instructions, 4 photon opcodes |
| Instruction Set | Red=ADD, Blue=SUB, Green=MUL, Yellow=DIV |
Target Markets
- Edge computing
- automotive ADAS
- industrial IoT
- client devices
Applications
- Real-time inference
- quantum key distribution
- embedded vision
- control systems
Manufacturing & Fabrication
| Foundry | GlobalFoundries / TSMC |
| PDK | GF 65nm or TSMC N65 (NDA) |
| EDA Flow | Commercial (Synopsys/Cadence) |
| Readiness | Architecture Ready -- Awaiting 65nm PDK |
Manufacturing Steps
- Obtain 65nm PDK under NDA
- Synthesize -> P&R -> DRC/LVS
- Package per FOUNDRY_STANDARDS.md
- Submit via foundry portal
Deliverables
- GDSII (mask layout)
- LEF (library exchange)
- DEF (design exchange)
- Gate-level netlist (Verilog)
- DRC report
- LVS report
- FOUNDRY_HANDOFF_SIMPLE.txt
- RTL (autophi_light_cpu_core.v + autophi_quantum_cpu_core.v + autophi_hybrid_cpu_top.v)
- Synthesis scripts
- P&R configurations
- Manufacturing documentation
- Performance projections
RTL Design Files
autophi_light_cpu_core.vautophi_quantum_cpu_core.vautophi_hybrid_cpu_top.v
Acquisition Path
This product is available through CGB's 4-step acquisition path. The current price is shown in your cart and on the live storefront page.
- Step 1 — Proof of Function: public, $1.69 each.
- Step 2 — Mathematical Deposition: reading material under mutual NDA.
- Step 3 — Evaluation License: hands-on evaluation under NDA; fee credits toward Step 4.
- Step 4 — Full Acquisition:
