What This Is
Spiral arrangements producing combined rotational and linear motion (screw action). ICs fire along the spiral path; the object follows the helix.
Specifications
| Parameter | Range / Options |
|---|---|
| Spiral Turns | 1 to 8 |
| ICs per Turn | 4 to 32 |
| Screw Pitch | Ultra-fine, fine, medium, coarse |
| Plate Ballast | Silicon, Ceramic, Aluminum, Copper, Cu-W, Diamond |
All configurations include:
- On-die Peltier electromagnetic cooling (Bi2Te3, 97% efficiency)
- Photon chromosome control (wavelength=opcode, polarization=operand, path=address, intensity=magnitude)
- Real seed data: 130nm, 20x20mm die, 1290 voxels, 1.29 TFLOPS/IC, AES COGS
- All 6 chip tiers: Entry, Mid, Pro, Peak, Unified, Volume
- 8 voxel types: LIGHT, MAGNETIC, ELECTRIC, HYBRID, QUANTUM, INTERCONNECT, IO, MEMORY + PELTIER
Peltier Electromagnetic Cooling
On-die Bi2Te3 thermoelectric junctions pump heat from computation to plate ballast. 97% efficiency. Adaptive per-zone cooling controlled by photon chromosome (COOL opcode, far-IR 1550nm band). No external cooling system needed.
Photon Chromosome Encoding
| Photon Property | IC Meaning | Example |
|---|---|---|
| Wavelength | Opcode | Red=ADD, Blue=SUB, Green=MUL, Yellow=DIV |
| Polarization | Operand | H=reg A, V=reg B |
| Path | Address | Waveguide route to target voxel |
| Intensity | Magnitude | Photon count = operand value |
Seed Specifications (Real)
| Parameter | 130nm Seed |
|---|---|
| Die Size | 20mm x 20mm (400 mm²) |
| Voxels per IC | 1,290 at 0.31 mm² each |
| FLOPS per Voxel | 1 GFLOPS |
| Compute per IC | 1.29 TFLOPS |
| Density | 3.225 GFLOPS/mm² |
| Power per IC | 400W |
| AES COGS per IC |
Applications
Precision feed mechanisms, micro-drills, micro-pumps, threaded micro-actuators, helical positioning systems.
Christopher Gabriel Brown
1341 Wellington Cove, Lawrenceville, GA 30043-5255, USA
Phone: • Email: crioneaka@outlook.com
Acquisition Path
This product is available through CGB's 4-step acquisition path. The current price is shown in your cart and on the live storefront page.
- Step 1 — Proof of Function: public, each.
- Step 2 — Mathematical Deposition: reading material under mutual NDA.
- Step 3 — Evaluation License: hands-on evaluation under NDA; fee credits toward Step 4.
- Step 4 — Full Acquisition: You are buying the blueprint. And the right to build it. Not to be used any other way.
