AutoPhi EM-IC Hybrid Combinations — 1000 Configurations (Peltier Cooled)
Publicly online since 2010 · U.S. patent applications since 2012 · inventions offered since 2014. The work of Christopher Gabriel Brown, independently documented.
What This Is
Mixed array shapes on one plate for multi-mode motion. Combine rotation + linear, positioning + thrust, or any combination for complex actuation.
1000
Hybrid Configs
10
Shape Combos
330.24
Max TFLOPS
2+
Motion Modes
Specifications
|
Parameter |
Range / Options |
|
Shape Combos |
Ring+Strip, Ring+Grid, Strip+Grid, Grid+Spiral, Full-Hybrid, etc. |
|
IC Count |
16 to 256 |
|
Motion Modes |
Primary + secondary (e.g., rotation + tilt) |
|
Plate Ballast |
Silicon, Ceramic, Aluminum, Copper, Cu-W, Diamond |
All configurations include:
- On-die Peltier electromagnetic cooling (Bi2Te3, 97% efficiency)
- Photon chromosome control (wavelength=opcode, polarization=operand, path=address, intensity=magnitude)
- Real seed data: 130nm, 20x20mm die, 1290 voxels, 1.29 TFLOPS/IC, $20K AES COGS
- All 6 chip tiers: Entry, Mid, Pro, Peak, Unified, Volume
- 8 voxel types: LIGHT, MAGNETIC, ELECTRIC, HYBRID, QUANTUM, INTERCONNECT, IO, MEMORY + PELTIER
Peltier Electromagnetic Cooling
On-die Bi2Te3 thermoelectric junctions pump heat from computation to plate ballast. 97% efficiency. Adaptive per-zone cooling controlled by photon chromosome (COOL opcode, far-IR 1550nm band). No external cooling system needed.
Photon Chromosome Encoding
|
Photon Property |
IC Meaning |
Example |
|
Wavelength |
Opcode |
Red=ADD, Blue=SUB, Green=MUL, Yellow=DIV |
|
Polarization |
Operand |
H=reg A, V=reg B |
|
Path |
Address |
Waveguide route to target voxel |
|
Intensity |
Magnitude |
Photon count = operand value |
Seed Specifications (Real)
|
Parameter |
130nm Seed |
|
Die Size |
20mm x 20mm (400 mm²) |
|
Voxels per IC |
1,290 at 0.31 mm² each |
|
FLOPS per Voxel |
1 GFLOPS |
|
Compute per IC |
1.29 TFLOPS |
|
Density |
3.225 GFLOPS/mm² |
|
Power per IC |
400W |
|
AES COGS per IC |
$20,000 |
Applications
Drone propulsion + gimbal, robotic multi-joint, aerospace multi-mode, medical compound actuators.
Note: The intellectual property portfolio (3,500+ inventions, 13+ USPTO patent applications) is not for sale. Only patterns and ICs are sold under license. IP remains the exclusive property of Christopher Gabriel Brown.
