Description

18-autophi-future — Copy  |  AutoPhi Future: Concept, Roadmap, Seed, and Ratio (SKU 2047)

Patent Status: U.S. Patent Application No. 18/370,908 — AutoPhi: Quantum battery integration & electromagnetic propulsion IC — filed 2023-09-21, pending examination at the USPTO Patent Center. U.S. Patent Application No. 19/540,453 — Integrated Technology Portfolio (umbrella) — filed 2026-02-13, pending examination at the USPTO Patent Center. Inventor: Christopher Gabriel Brown . Patent pending. All rights to seek additional patent protection are expressly reserved by the inventor.

Overview

AutoPhi Future (Project 18) is the exhaustive, forward-looking concept and roadmap repository for the entire AutoPhi semiconductor stack. It is one vessel : the original Project 18 concept enlarged by folding the re-engineered Project 19 (AutoPhi Miracle) into it — ratio, miracle calculation, seed matrix, valuation, quantum-photonic executable-seed path, standalone RAG, sell-and-distribute readiness, and complete clarity on what is quantum versus what is classical. One number, one reality. The product is not the chip as object; the product is the ratio of instruction set (from size) to calculation and performance per exchange .

This “Copy” variant (SKU 2047) contains the same technology base as the primary 18-autophi-future package. It shares the identical seed architecture, photon-chromosome encoding, metal-tree structure, nine technology elements, and the full MANIFEST of 7,661 files spanning HDL, EDA flow output, documentation, data, chemistry/bio artefacts, source code, images, layout, and web content.

Maturity Level: 4 — Tape-out / Mass-Manufacturable.

What This Product Sells

The product is the ratio : instruction set (from size) → calculation (FLOPS) and performance per exchange (per dollar, per watt, per area). You supply envelope and node (size); you receive calculation and performance per exchange. No mainstream roadmap states that. The formulas are in the open; the ability to build seeds from the ratio is in the repository. That is the product.

Term Definition

Instruction Set The canonical encoding; what is input as the result; the seed and its growth into nodes.

Size Voxel-to-nm dimensions, the envelope, real height × width in a wafer run.

Calculation The outcome to be found; FLOPS, ZettaFLOPS in real H × W — the miracle we call calculation.

Performance per Exchange Work per unit of area, power, and cost; the right ratio.

The Miracle We Call Calculation

ZettaFLOPS in real height and width, inside a normal run of an IC wafer: the right ratio in voxel-to-nm, the envelope, the power and cooling, the AES and COGS. That outcome to be found — the concrete dimensions and the number that put the whole chip, born at once, inside a real run — that is the miracle we call calculation. We build the whole chip at one birth. We input the result as the instruction. We draw the voxel, plan the pins, grow from root to trunk to branch to leaves. We add light and electrons when needed and transform into quantum. The finding of that ratio, that envelope, that number, is the miracle we call calculation. The value of a capability you never had is not a number.

The Metal Tree — Structure, Not Metaphor

AutoPhi Future posits a metal tree that computes . No water. No biological leaves. What flows through it is data; what it draws in is light; what it turns that light into is electricity to function. The chip is not a metaphor of a plant; it is a structure that fulfils the same roles in metal and in computation.

Tree Role (Metal) Chip Analogue (Voxel Role)

Intake / Roots Energy intake — optical/power input; voxels that receive light and feed the rest.

Trunk / Vascular Send — data, control, quantum state, power along waveguides, TSVs, and wires.

Light → Energy Voxels that convert light energy emission to electricity. Light in, electricity out.

Cool & Support Voxels that cool the others and help both: EM cooling, thermal interface, structure.

Voxel types — the species of this tree: INTERCONNECT , LIGHT , BLANK , HYBRID , QUANTUM , IO , MEMORY , CROSS . Mapped to tree roles: SEND (INTERCONNECT, CROSS, LIGHT as waveguide/router), ENERGY (LIGHT as light→electricity, IO as power/light in), COOL_SUPPORT (BLANK extended to thermal/decap/support, or dedicated COOL voxel). Compute and storage consumers: HYBRID, QUANTUM, MEMORY, IO.

The Photon Chromosome — DNA-Style Encoding for the Voxel

Each voxel cell carries a DNA-style encoding across three strands — electron (classical), atomic (quantum), and photon (light). The photon chromosome encodes the real form in light. Four quantities map directly to computation:

Photon Quantity Symbol Computational Mapping

Wavelength (colour) λ Opcode (Red = ADD, Blue = SUB, Green = MUL, Yellow = DIV; extensible)

One photon chromosome = (λ, pol, path, I) = (opcode, operand/phase, address, magnitude). This is the photon analogue of the classical (opcode, operands, result) and quantum (gate, mask, phase) chromosomes. The light trigger — single-photon computation initiation — starts the cell cycle. Three strands, one cell, one trigger.

The seed is the minimal, canonical specification from which every build is grown. It is not a single file; it is the canonical set:

Seed Component What It Defines Source File

Chip Series (Tiers + COGS) Entry → Peak → Volume; CPU/GPU/DPU/all-in-one; COGS bands docs/chip_series_cpu_gpu_dpu.yaml , CHIP_SERIES_CPU_GPU_DPU.md

Voxel Roles Tree roles: SEND, ENERGY, COOL_SUPPORT; 8 voxel types VOXEL_PLANT_CHIP_LIGHT_FORM.md

Photon Chromosome Form in light: (λ, pol, path, I) VOXEL_CELL_DNA_AND_PHOTON_CHROMOSOMES.md

Nine Technology Elements LED recycling, vertical threading, nanophotonic flow, QEC, cooling, quantum battery, hybrid, neuromorphic engine PERFORMANCE_AND_COGS_SUMMARY.md , 27/28 NINE_TECHNOLOGIES

Performance + Decisive COGS One-page metrics and AES COGS paths ($5K–$20K) PERFORMANCE_AND_COGS_SUMMARY.md

Seed manifest: seeds/SEED.yaml — version 1, name “AutoPhi chip seed (18),” six axes: tiers, cogs_bands, cpu_gpu_dpu_all_in_one, voxel_roles, photon_chromosome, nine_tech. Reproducibility: same seed, same inputs, same result. Version the seed; version the chips. The seed defines the unit; scaling is by repeating and tiling — segment, stack, volume.

Executable Seed — The Blank Voxel (RTL, GDSII, LEF)

The executable portion of the seed is one or more voxels built through OpenLANE2 to GDSII and LEF. The reference implementation:

Inputs (17 signals) light_trigger , light_wavelength[7:0] , light_intensity[7:0] , laser_red[7:0] , laser_blue[7:0] , laser_green[7:0] , laser_yellow[7:0] , qinst_opcode[7:0] , qinst_qubit_mask[QUBITS-1:0] , qinst_classical[CLASSICAL_BITS-1:0] , clk , rst_n

Outputs (7 signals) color_result[7:0] , operation_mode[1:0] , light_computation_complete , quantum_state[QUBITS-1:0] , quantum_fidelity[7:0] , hybrid_computation_complete , total_operations[31:0]

Behaviour BLANK — all outputs tied to zero; same footprint as hybrid voxel so the grid can swap types without rewiring.

OpenLANE2 configuration ( scripts/openlane_seed_design/config.json ):

PDK: SkyWater 130 nm (sky130) via volare at PDK_ROOT . Growth into 3 nm and 5 nm uses the same RTL and flow concept; only the foundry PDK and node-specific parameters change (CLOCK_PERIOD 0.5–1 ns range; foundry-specific keys). Target foundries: TSMC, Samsung, Intel, SkyWater, GlobalFoundries.

EDA flow runs captured in the package: Multiple OpenLANE2 runs dated 2026-02-07, including full 57-step flows (01-verilator-lint through 57-klayout-streamout). Final artefacts include autophi_voxel_blank.gds , autophi_voxel_blank.magic.gds , autophi_voxel_blank.klayout.gds , STA corner results across three PVT corners (nom_ff_n40C_1v95, nom_ss_100C_1v60, nom_tt_025C_1v80), and all intermediate synthesis, floorplan, placement, CTS, and routing reports.

1 Entry Low Yes (primary) No or minimal No No Single die, control only; lightest footprint.

2 Mid Low–Mid Yes Yes (small) No No CPU + small GPU; edge/client.

3 Pro Mid Yes Yes (full) Yes (optional) No Workstation / server.

4 Peak Expensive Yes Yes (max) Yes (full) No Multi-die or large die; datacenter-grade.

5 Unified Mid Yes Yes Yes Yes Single die CPU+GPU+DPU; Project 28 complete unit.

6 Volume Low Yes Yes Yes Yes Same all-in-one at volume; COGS back down.

AES (from Latin aes = bronze) is the code name for “actual” — actual cost, actual price to function. Documented COGS paths: $20K AES COGS at 1B volume, 3 nm, 240 dies, 5–10 year path; $5K AES COGS at 10B volume, 1 nm, 12 dies, 10–15 year path.

1 LED Power Recycling 90% efficiency; 42% net power reduction; light-to-electrical; zero net power, continuous operation. Prior-art patents: US 2012/0305059 A1, US 4,775,876, US 2002/0170591 A1, US 2007/0085100 A1 (not owned by inventor; defensible via nine-element integration).

2 Vertical Threading 12,000 TSVs/mm²; 125 TB/s bandwidth.

3 Chiplet Stacking 500 layers; 18 per stack; 800-layer 3D stacking demonstrated in REV_H (ultra-thin die ~0.0875 mm/layer).

4 Nanophotonic Data Flow 1,400 TB/s; 2,800 optical channels; silicon photonic waveguides; sub-ns latency; 1,000× power efficiency.

5 Quantum Error Correction 99.998% fidelity; 1,400 logical qubits; surface code.

6 Electromagnetic Cooling 97% efficiency; 32 thermal zones; zero-moving-parts; magnetic heat transfer; quantum coherence optimisation. Patents: 1096, 1097, 1098.

7 Quantum Battery Layers 20 layers; 1,500 Wh capacity; 75 MW burst.

8 Quantum–Classical Hybrid Seamless integration; real-time quantum–classical interface; readout and control.

9 Neuromorphic AI Engine Event-driven; 1M+ artificial neurons (spiking, STDP); memristor-based.

System-level (AQCHS): 32,768+ TOPS, 150 TB/s photonic interconnect, 4,096 superconducting qubits (Josephson junction, 99.9% fidelity), 1M+ artificial neurons, quantum memory (1 ms+ coherence).

REV_H scaled card (800×): 2.8 ZettaFLOPS peak, 5 PB memory, 9.83M qubits, 3.2B neurons, 360 PB/s bandwidth, 4.8M optical channels, 2,400 dies integrated, 280 kW power, PCIe form factor (268 mm × 111 mm × 70 mm), 2U+ server compatible. Cost optimised from $250.4M down to $5K–$20K target (12,500×–50,000× reduction). Integrated custom memory: 6.256 TB at $0 additional cost (quantum + photonic + neuromorphic reuse; no external HBM dependency).

Note: system/card vs single GPU — different categories; comparison for context only.

The Seed Matrix — Formulas in the Open

A matrix formula table to build seeds from the ratio. Inputs, outputs, and the formulas that connect them:

Inputs (you supply) Outputs (formulas give)

scenario_id, node_nm, H_mm, W_mm, a_v_mm², f_v_flops, power_w, aes_usd S_mm², N_v (voxel count), C_flops (total calculation), ρ (FLOPS/mm²), P_per_dollar, P_per_watt

Worked example (130 nm): H=20 mm, W=20 mm, a_v=0.31 mm², f_v=1×10&sup9; FLOPS, power=400 W, AES=$20,000 → S=400 mm², N_v≈1,290 voxels, C≈1.29×10¹² FLOPS, ρ≈3.225×10&sup9; FLOPS/mm², P_per_dollar≈6.45×10&sup7; FLOPS/$, P_per_watt≈3.225×10&sup9; FLOPS/W.

Seed matrix deliverables in the repository: seeds/seed_matrix_template.csv (template with input and output columns, any number of rows), seeds/seed_matrix_example.json (JSON with “inputs” and “computed” blocks), docs/SEED_MATRIX_FORMULA.md (complete formula table), docs/SEED_MATRIX_IMPORT.md (usage guide — CSV/JSON, any size, truncated OK).

Blu-ray Harvest — 25 GB Distributable Builds

Every build can be written to a 25 GB Blu-ray disc : foundry handoff packages, standards, performance metrics, decisive COGS, and Seeds/ when present. The disc is distributable and resellable under chosen terms.

Build script: scripts/build_bluray_foundry.py — packages from Project 24 (foundry packages) + Performance_And_COGS from Project 18/docs + Seeds from 18/seeds into a Blu-ray-ready folder. Companion batch: scripts/build_bluray_foundry.bat .

Each Blu-ray build contains: Performance_And_COGS/CHIP_SERIES_CPU_GPU_DPU.md (5,042 bytes), Performance_And_COGS/CODE_NAME_ACTUAL_BRONZE.md (2,044 bytes), Performance_And_COGS/PERFORMANCE_AND_COGS_SUMMARY.md (2,659 bytes), Seeds/README.md (1,596 bytes), Seeds/SEED.yaml (803 bytes), Seeds/seed_matrix_example.json (604 bytes), Seeds/seed_matrix_template.csv (199 bytes).

• Option A: Single voxel-plan spec (JSON/YAML) — defines voxel types, default type map for a given die size, allowed compositions (H, V, diagonal, cross, Z).
• Option B: Parameter set in RTL — VOXEL_PLAN_W , VOXEL_PLAN_H , VOXEL_TYPE_MAP[i][j] , CONNECT_DIAG , CONNECT_CROSS , N_LAYERS .
• Option C: Propagate to Project 28 (Complete Unit) — CPU domain = one voxel grid, accelerator domain = REV morphism.
• Option D: Tooling propagation — OpenLANE configs derive from the same voxel plan.

Path options:

• E: Neighbour connectivity (rect N/S/E/W, optional diagonal, optional cross).
• F: Classical vs quantum path tagging.
• G: Critical path and depth (logical path, calculation depth for coherence).
• H: Vertical (Z) paths across chiplet layers (TSV, hybrid bond).

Whole-quantum calculation options:

• I: Unified state representation (global state vector or density matrix).
• J: Global Hamiltonian or circuit (one evolution over all qubits).
• K: Hierarchical / reduced model (one effective Hamiltonian per cluster).
• L: Classical–quantum boundary interface (measurement, control, feed-forward).
• M: Single simulation/spec target script.

Quantum vs Classical — Honest Statement

The vision includes quantum: QUANTUM voxel type, whole-quantum options, hybrid quantum–classical, nine technology elements. The seed built today is classical : one cell, built with OpenLANE2 (synthesis + P&R), SkyWater 130 nm. No qubits in that block. Quantum is the path available when the right voxel types and RTL are added (in Projects 27/28 and beyond). No hand-waving. No scam. No one is lost.

How chips are made in AutoPhi: RTL (from 27/24/28) → synthesis (Yosys) → OpenLANE2 P&R → GDSII/LEF → foundry or package. Project 18 provides the seed voxel build (one cell), the ratio and seed matrix (formulas, CSV, JSON), and the Blu-ray packaging. Projects 24/27/28 provide the full RTL and build flows for bigger dies and systems.

02 (AutoPhi Modern) Product consolidation; 18 is the future vision that informs how the voxel and paths evolve. REV_H: 2.8 ZF, 39,756+ handoff files.

24 (Scale) Foundry packages; 18's build script sources 24 by default for Blu-ray content.

27 (Scale Ultimate) Voxel die building, hybrid/light/quantum cores, segment RTL. 18's cell and chromosome concepts apply to 27's grid. Seed RTL (autophi_voxel_blank) originates from 27.

28 (Complete Unit) Single-chip, CPU–accelerator symmetry. 18's whole-quantum and path options inform 28's unified die.

1st 96-333-fixed.csv ~1,759 rows, ~2.5M chars. CSV catalog: 96–333 product/deposition entries, light trigger, semiconductor, patent references, product names, SKUs.

2nd Yesterday.txt ~142 lines. AutoPhi $2.8475T portfolio: AQCHS, qubits, photonic interconnect, neuromorphic, 142 IC designs, applications, markets, valuation.

3rd 18-autophi-future docs (all) Concept, paths, notes, improvements, voxel-cell, photons/electrons computational, next generation.

4th 1 light trigger.txt ~1,770 lines. Full text for the light-trigger deposition.

Standalone RAG folder: rag/ with copies of key 18-docs for offline retrieval.

Top file extensions: .json (2,704), .rpt (1,768), .txt (728), .log (504), (no ext) (341), .tcl (304), .md (262), .v (244), .def (143), .sdc (124), .sdf (108), .lib (76), .odb (41), .ext (37), .html (32).

START_HERE.md Quick-links entry point for new users.

DEEP_DIVE_EXHAUSTIVE_PITCH.md Full exhaustive reveal: ratio, miracle, seed matrix, valuation, 19 into 18, Blu-ray, quantum, sell and distribute.

SALES_DESCRIPTION.md Tight sales description for product pages (short, full, and long-form variants).

DEPOSITION_AUTOPHI_FUTURE.md Full deposition: metal tree, seed, tiers, AES, executable seeds, Blu-ray harvest.

VOXEL_CELL_DNA_AND_PHOTON_CHROMOSOMES.md Voxel as cell; DNA-style encoding; three chromosomes; photon chromosome.

VOXEL_PATHS_AND_WHOLE_QUANTUM_OPTIONS.md Paths through the grid; options to calculate as a whole quantum.

VOXEL_PLANT_CHIP_LIGHT_FORM.md Metal tree organisation; light as real form; computer that computes using form in light.

CHIP_SERIES_CPU_GPU_DPU.md + .yaml Six-tier chip series; CPU/GPU/DPU/all-in-one data model.

PERFORMANCE_AND_COGS_SUMMARY.md One-page performance metrics + decisive COGS; AES paths $5K–$20K.

SEED_FOR_GROWING_CHIPS.md What the seed is; why it is needed; where it lives; executable seeds.

SEED_MATRIX_FORMULA.md Matrix formula table: variables, formulas, cross-matrix.

SEED_MATRIX_IMPORT.md CSV/JSON import; no small tool; any size; truncated OK.

SEED_VOXEL_OPENLANE2.md How to build the seed voxel with OpenLANE2.

SEED_GROWTH_3NM_5NM.md Path from 130 nm to 3 nm and 5 nm; creation, growth, strength.

SEED_VOXEL_BIGGER_BETTER_MORE.md Traditional methods; foreseen result; ZettaFLOPS in real H×W; Rubik's-cube pin planning; whole chip at one birth.

PRODUCT_RATIO.md What we sell: the ratio.

MIRACLE_CALCULATION.md ZettaFLOPS outcome; the naming of the thing: calculation.

VALUATION.md Indicative valuation; $500B is not even close.

ESSAY_19_INTO_18.md The unrational change to reality: 19 going into 18.

DEEP_VIEW_7T.md Break rules, smash windows, make way. Full stack, valuation, humanitarian.

LOGICAL_SALES_PITCH.md One exhaustive logical sales pitch: all deep dives unified; single read, single story.

CODE_NAME_ACTUAL_BRONZE.md AES code name: bronze = actual, real to touch, real price to function.

PROCESSOR_POWER_COMPARISON.md AutoPhi vs other processors (NVIDIA H100, Apple M4, AMD EPYC, Intel Xeon).

QUANTUM_AND_HOW_CHIPS_ARE_MADE.md Quantum vs classical; concrete chip-making flow; no hand-waving.

DISTRIBUTION_AND_LICENSING.md Can you distribute? Yes; add LICENSE when terms are fixed.

SELL_AND_DISTRIBUTE.md Readiness checklist: product, pitch, COGS, channels, optional LICENSE.

RAG_FOR_18.md Retrieval sources and index order for Project 18.

ALL_COMPONENTS_FROM_RAG.md Consolidated component list from all RAG sources.

NOTES_OVERCOME_02_QUANTUM_PROCESSOR.md Challenges overcome in 02: REV_H scaling, cost, memory, server compatibility.

NOTES_OVERCOME_24_25_26.md Challenges overcome in Scale 24, 25, 26.

27_28_NEEDS_AND_IMPROVEMENTS.md Projects 27/28: needs and improvements.

PARTS_NEED_IMPROVEMENT.md Open work; next generation direction.

SEED_RUN_COMPLETE.txt Where outputs are when the seed run completes.

pitch/index.html Sales pitch: one seed, every foundry, metal tree, tiers, AES, Blu-ray.

pitch/deep-dive.html Deep dive: metal tree, seed, photon chromosome, chip series, executable seeds.

pitch/deep-dive-exhaustive.html Full exhaustive reveal.

pitch/deep-view-7t.html Deep view for the 7T ask.

pitch/logical-sales-pitch.html All deep dives unified in one logical pitch.

pitch/deposition.html Full deposition (HTML).

pitch/sales-pitch-complete.html One-page complete pitch (index + deep-dive + deposition + valuation).

pitch/sales-description.html Product-page sales description.

pitch/sales-description-embed.html Embeddable fragment for live site.

pitch/miracle-calculation.html The miracle we call calculation.

pitch/valuation.html Valuation (indicative range, what is valued, contact).

pitch/essay-19-into-18.html The unrational change to reality.

pitch/wordpress-seed-voxel-foundation.html Seed voxel foundation article.

pitch/wordpress-seed-voxel-foundation.wxr WordPress import (categories and tags).

Images (8 PNG files): autophi-future-hero, one-seed-many-harvests, patent-descriptive, photorealistic-chip, tiers-arc, photoreal-die-or-package, photoreal-workspace-gds.

scripts/run_seed_openlane_wsl.sh Run OpenLANE2 for the seed voxel (Nix/Docker/venv); copies GDS/LEF to seeds/. Env vars: OPENLANE_USE_NIX, OPENLANE_USE_DOCKER, WORK, OPENLANE2_ROOT, PDK_ROOT.

scripts/apply_openlane2_nix_patch.sh Apply Nix doCheck patch so OpenLANE2 flake builds.

scripts/nix/openlane2-disable-doCheck.patch Nix patch file for OpenLANE2.

scripts/build_bluray_foundry.bat Windows batch for Blu-ray packaging.

scripts/generate_7t_seed_wordpress_import.py Generate WordPress import for 7T seed articles.

scripts/openlane_seed_design/config.json OpenLANE2 configuration for the seed voxel (560×560 μm die area).

scripts/openlane_seed_design/autophi_voxel_blank.v Seed voxel Verilog RTL (BLANK type, 39 lines).

create_depositions_product.py Magento product creation for CGB Mathematical Depositions Complete Collection; SFTP upload + REST API product and image creation. Ten depositions (Harmonic Decay Function, Entropic Bridge Equation, Voxel Resonance Matrix, Photon-Chromosome Mapping, Recursive Growth Operator, Zero-Point Energy Lattice, Golden Spiral Convergence, Quantum Counting Theorem, Thermal Noise Filtration, Dimensional Fold Transform).

final_check_960.py Final verification of 960px image dimensions.

find_960.py Find images at 960px width.

fix_960px.py Fix images to 960px width standard.

inspect_960px.py Inspect 960px compliance.

MANIFEST.json Machine-readable package manifest: 7,661 files, maturity level 4, patent applications, key artefacts by category.

CITATION.cff CFF v1.2.0 citation metadata; date-released 2026-05-02; license LicenseRef-Proprietary-CGB.

LICENSE Proprietary and confidential; no license granted; patent notice (18/370,908 and 19/540,453).

CHANGELOG.md Keep a Changelog format; unreleased 2026-05-02: scaffold files added.

CONTACT_INFO.txt Christopher Gabriel Brown, Lawrenceville, Georgia.

PLAYBOOK.md Internal playbook; scaffolded 2026-05-11; sector: Computing & Semiconductors; audience: AI chip cos, fabless designers, foundries, EDA vendors, HPC sites.

PRIOR_ART_LED_RECYCLING.md Third-party prior art for LED recycling element (US 2012/0305059 A1, US 4,775,876, US 2002/0170591 A1, US 2007/0085100 A1); defensible via nine-element integration.

Yesterday.txt Portfolio summary (~142 lines): AQCHS, 142 ICs, qubits, photonic, neuromorphic, valuation.

7T_SEED_REST_AS_SERVICE_PLAN.md REST-as-service plan for 7T seed.

7T_SEED_WORDPRESS_IMPORT_README.md WordPress import instructions for 7T seed articles.

wordpress-post-three-projects.md WordPress post covering three related projects.

autophi-future-articles-import.wxr WordPress WXR import for AutoPhi Future articles.

7t-seed-50-articles-wordpress-import.xml WordPress XML import for 50 seed-topic articles.

• 7,661 files across 10 categories (Data, EDA flow output, Documentation, HDL, Chemistry/bio, Web, Source code, Images, Layout, Other).
• Seed voxel RTL — autophi_voxel_blank.v (Verilog, 39 lines, parameters QUBITS=256, CLASSICAL_BITS=32, SECURITY_LEVEL=3).
• OpenLANE2 configuration — config.json (560×560 μm die area, 10 ns clock, 45% target density).
• Complete EDA run artefacts — Multiple OpenLANE2 runs (2026-02-07) with full 57-step flows: verilator-lint, yosys-synthesis, openroad-floorplan, placement, CTS, routing, STA (3 PVT corners), magic-streamout, klayout-streamout. Final GDSII layout files ( .gds , .magic.gds , .klayout.gds ).
• Seed manifest — seeds/SEED.yaml (version 1, six axes).
• Seed matrix — seed_matrix_template.csv + seed_matrix_example.json + formula documentation.
• 36 documentation files in docs/ covering every aspect: product ratio, miracle calculation, metal tree, photon chromosome, chip series, performance/COGS, seed growth (130 nm → 3 nm/5 nm), voxel paths, whole-quantum options, distribution/licensing, valuation, RAG, prior art, sales description, deposition, essays, and more.
• 14 HTML pitch pages + 8 PNG images + WordPress import files (.wxr, .xml).
• 4 Blu-ray build folders (future-only, 2026-03-14) with MANIFEST, Performance_And_COGS, and Seeds.
• Build and automation scripts — shell (WSL seed build, Nix patch), batch (Blu-ray), Python (WordPress import generation, Magento product creation, image utilities).
• RAG folder — standalone retrieval sources (CSV catalog, portfolio, 18-docs copies).
• Chip series YAML — structured data model for all six tiers.
• Prior art analysis — LED recycling prior-art patents with defensive strategy.
• CITATION.cff , LICENSE (proprietary, patent notice), CHANGELOG.md , CONTACT_INFO.txt , MANIFEST.json , PLAYBOOK.md .

How this is delivered

This package ships on a single Blu-ray disc, posted to the delivery address on your order. The archive on the disc is AES-256 encrypted; the passphrase is sent separately, by email, once the disc is despatched — so the disc alone is of no use to anyone who intercepts it.

Discs are despatched by tracked, signed-for post. Allow 5 business days for mastering and verification before despatch.

Disclaimer: All products on this store are fictional ICs and designs. They represent conceptual semiconductor architectures, roadmaps, and design artefacts. No physical silicon is included. No intellectual property rights are conveyed with purchase; the buyer acquires commercialisation rights only. Products are priced at a single tier reflecting the scope and depth of the design work and conceptual innovation contained within.

© 2026 Christopher Gabriel Brown. All rights reserved.
